800G

  1. You are here:
  2. Home
  3. Product solutions
  4. 800G
  5. 800G AOC OSFP & QSFP-DD800
Straight
Straight
1 / 2
Breakout
2 / 2

800G AOC OSFP & QSFP-DD800

Eoptolink 800G AOC are compliant to the latest releases of the OSFP & QSFP-DD800 MSA. We manufacture straight 800G to 800G or breakout 800G to 2x400G types, both for multi-mode and single-mode application. On 800G side can be either OSFP or QSFP-DD form-factor, on 400G side OSFP112-RHS or QSFP112. DSP or LPO types can be ordered and in mass production with industry lowest power consumption and robust performance.

    AOC:

    • DSP Retimed based solutions
    • Support 8x106.25Gbps and electrical interface
    • OSFP, QSFP-DD and QSFP112 MSA compliant
    • Up to 30m
    • 0-70C
    • CMIS 5.0 and above

    LPO AOC:

    • LPO based solutions
    • Support 8x106.25Gbps and electrical interface
    • OSFP, QSFP-DD and QSFP112 MSA compliant
    • 8.5W OSFP
    • 8.5W QSFP-DD800
    • 4.5W QSFP112

    Most common types are shown, if you are looking for custom made part, please, contact us

    AOC Type Speed Solution AOC MPN Left side Left Right side Right Cable Color
    OSFP to OSFP 800G to 800G DSP EOLO-8HG-PCT-XX MPO-16 gray MPO-16 gray aqua blue
    QSFP-DD to QSFP-DD 800G to 800G DSP EOLD-8HG-PCT-XX MPO-16 beige MPO-16 beige aqua blue
    OSFP to QSFP-DD 800G to 800G DSP EOLO-8HG-PCT-XX-GX MPO-16 beige MPO-16 beige aqua blue
    OSFP to 2xQSFP112 800G to 2x400G DSP EOLO-8HG-PCT-XX-CX MPO-16 beige MPO-12 beige aqua blue
    QSFP-DD to 2xQSFP112 800G to 2x400G DSP EOLD-8HG-PCT-XX-CX MPO-16 beige MPO-12 beige aqua blue
    OSFP to 2xOSFP112 RHS 800G to 2x400G DSP EOLO-8HG-PCT-XX-BX MPO-16 beige MPO-12 beige aqua blue
    QSFP-DD to 2xOSFP112 RHS 800G to 2x400G DSP EOLD-8HG-PCT-XX-BX MPO-16 beige MPO-12 beige aqua blue

    For the latest specification and samples, please, contact usThis email address is being protected from spambots. You need JavaScript enabled to view it.

    Most common types are shown, if you are looking for custom made part, please, contact us

    AOC Type Speed Solution AOC MPN Left side Left Right side Right Cable Color
    OSFP to OSFP 800G to 800G LPO EOLO-138HG-PCT-XX-SLX MPO-16 gray MPO-16 gray yellow
    OSFP to OSFP 800G to 800G DSP EOLO-138HG-PCT-XX-SX MPO-16 gray MPO-16 gray yellow
    QSFP-DD to QSFP-DD 800G to 800G LPO EOLD-138HG-PCT-XX-SLX MPO-16 gray MPO-16 gray yellow
    QSFP-DD to QSFP-DD 800G to 800G DSP EOLD-138HG-PCT-XX-SX MPO-16 gray MPO-16 black yellow
    OSFP to 2xQSFP112 800G to 2x400G LPO EOLO-138HG-PCT-XX-CSLX MPO-16 gray MPO-12 gray yellow
    OSFP to 2xQSFP112 800G to 2x400G LPO EOLD-138HG-PCT-XX-CSLX MPO-16 gray MPO-12 gray yellow

    For the latest specification and samples, please, contact usThis email address is being protected from spambots. You need JavaScript enabled to view it.
