Coherent OSFP 800G ZR
1 / 1

800G OSFP ZR Coherent

The EOLO-168HG-B-XXXSX OSFP 800G ZR transceiver is complaint to the OIF-800ZR standard. The modules is based optical engine and the latest coherent DSP for 800G transmission. The OSFP form-factor and CMIS5.0 support makes them suitable for use in transmission and Ethernet switching

    • Supports 850Gbps
    • Single 3.3V Power Supply
    • OSFP MSA compliant
    • RoHS compliant
    • 8x106.25Gbps (PAM4) electrical interface
    • Duplex LC connector
    • Commercial case temperature range of 0°C to 70°C
    • I2C interface with integrated Digital Diagnostic Monitoring
    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLO-168HG-B-XXXSX OSFP 800G ZR 850G DWDM 120km LC C-Temp

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.
