X2 to SFP+ converter
1 / 1

X2 to SFP+ converter

Eoptolink X2 to SFP+ and XENPAK to SFP+ converter enables migration from X2/XENPAK form factors to SFP+ without having to upgrade or replace the switches. Can be used with SR, LR, EZ, ZR, BIDI, CWDM or DWDM Eoptolink SFP+ optical transceivers.

    • Compatible with X2/XENPAK MSA
    • Case Temperature Range: Standard: 0°C - 70°C
    • Hot pluggable 70-pin connector with XAUI electrical interface
    • Management and control via MDIO 2-wire interface
    • Complaint with the EU RoHS 6 Environmental requirements
    • Diagnostic Optics Monitoring
    • 10GE Ethernet switches and routers
    • 10GE Core-routers
    • 10GE Storage
    • Other 10Gbps Ethernet Transmission System
    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOL2-PCT X2 to SFP+ converter 10.3125Gbps N/A N/A N/A C
    EOLP-PCT XENPAK to SFP+ converter 10.3125Gbps N/A N/A N/A C
