The Eoptolink BIDI 4G series is small form factor pluggable module for 4x/2x/1x Fibre Channel and 1000BASE-BX Gigabit Ethernet single fiber communications. It is with the SFP 20-pin connector to allow hot plug capability. The transmitter section uses class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
1 / 2
2 / 2
4G BIDI SFP
- Fiber Bi-Directional SFP Optical Transceiver
- Up to 4.25 Gb/s
- Compliant with Fibre Channel FC-PI 400/200/100
- Compliant with IEEE 802.3ah-2004 1000BASE-BX
- Simplex LC Connector or SC connector
- AC/AC Coupling according to MSA
- Single +3.3 V Power Supply
- RoHS Compliant
- 0 to 70C, -10 to 85C or -40 to 85C Case Operation Temperature Ranges
- Class 1 Laser International Safety Standard IEC 60825 Compliant
- Fiber Channel Links
- WDM Gigabit Ethernet Links
- Other Optical Links
| Part No. | Description | Data Rate | Wavelength | Distance | Connector | Temp. |
| EOLS-BI1348-M-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 100m | LC | C/I |
| EOLS-BI1548-M-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 100m | LC | C/I |
| EOLS-BI1348-5-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 5km | LC | C/I |
| EOLS-BI1548-5-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 5km | LC | C/I |
| EOLS-BI1348-10-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 10km | LC | C/I |
| EOLS-BI1548-10-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 10km | LC | C/I |
| EOLS-BI1348-20-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 20km | LC | C/I |
| EOLS-BI1548-20-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 20km | LC | C/I |
| EOLS-BI1348-30-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 30km | LC | C/I |
| EOLS-BI1548-30-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 30km | LC | C/I |
| EOLS-BI1348-40-D | BIDI 4G SFP | 4.25Gbps | 1310nm/1550nm | 40km | LC | C/I |
| EOLS-BI1548-40-D | BIDI 4G SFP | 4.25Gbps | 1550nm/1310nm | 40km | LC | C/I |
| EOLS-BI1648-11XXD | BIDI 4G SFP | 4.25Gbps | CWDM/CWDM | 11dB | LC | C/I |
| EOLS-BI1648-18XXD | BIDI 4G SFP | 4.25Gbps | CWDM/CWDM | 18dB | LC | C/I |
| EOLS-BI1648-24XXD | BIDI 4G SFP | 4.25Gbps | CWDM/CWDM | 24dB | LC | C/I |
For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.
