Eoptolink's 32G SFP28 transceivers are suitable for FibreChannel and 25G Ethernet applications. They are designed for use in 25/28G Gbps links over multimode or single mode fiber. They are compliant to IEEE 802.3by, SFF-8472 Rev 12.2 and SFF-8402, and compatible with SFF-8432 and applicable portions of SFF-8431 Rev. 4.1. The optical transceiver is compliant per the RoHS Directive 2011/65/EU.
1 / 2
2 / 2
32G SFP28
- Up to 25.78, 27.95, 28.05 Gb/s bi-directional data links
- Build-in CDR
- Hot-pluggable SFP+ footprint
- Built-in digital diagnostic functions
- Duplex LC connector
- RoHS compliant
- Metal enclosure, for lower EMI
- 1.2W maximum power consumption
- Single 3.3V power supply
- Operating temperature range: 0°C to 70°C or -10°C to 70°C
- OUT4
- 32GFC
- CPRI Option 10
| Part No. | Description | Data Rate | Wavelength | Distance | Connector | Temp. |
| EOLP-8528G-02-R | SFP32 SR | up to 28.05Gbps | 850nm | 100m | LC | C |
| EOLP-1328G-02-R | SFP32 LR lite | up to 28.05Gbps | 1310nm | 2km | LC | C |
| EOLP-1328G-10-R | SFP32 LR | up to 28.05Gbps | 1310nm | 10km | LC | C |
