1.6T

  1. You are here:
  2. Home
  3. Product solutions
  4. 1.6T
  5. 1.6T OSFP
OSFP 1.6T DR8-2
OSFP 1.6T DR8-2
1 / 5
OSFP 1.6T DR8
2 / 5
OSFP 1.6T DR8-2
3 / 5
OSFP 1.6T DR8
4 / 5
OSFP 2x800G FR4
5 / 5

1.6T OSFP

Eoptolink OSFP 1.6T transceivers firmware supports CMIS 5.0 and newer release. We offer transceivers for DR8, DR8-2, 2VR4, 2FR4 and 4FR2 interfaces. Our vertical integration for optical engines enables leading performance and per consumption.

    • Supports 212.5Gbps/s
    • Single 3.3V Power Supply
    • 212.5Gbps (PAM4) optical interface
    • 212.5Gbps (PAM4) electrical interface
    • 106.25Gbps (NRZ) electrical interface
    • Commercial case temperature range of 0°C to 70°C
    • CMIS 5.0 or later version
    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLO-85T-01-DX OSFP 1.6T 2VR4 8x200G 850nm TBD TBD C
    EOLO-13T-5H-XDX
    EOLO-13T-5H-XMX    		 OSFP 1.6T DR8 8x200G 1311nm 500m Dual MPO-12
    MPO-16    		 C
    EOLO-13T-02-XDX
    EOLO-13T-02-XMX    		 OSFP 1.6T DR8-2 8x200G 1311nm 2km Dual MPO-12
    MPO-16    		 C
    EOLO-16T-02-XXX OSFP 1.6T 2FR4 8x200G CWDM 2km Dual Duplex LC C
    EOLO-16T-02-TX OSFP 1.6T 4FR2 4x400G 1291nm/1311nm 2km SN C

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.
