OSFP 4x200G VR4
OSFP 4x200G VR4
1 / 3
OSFP 4x200G DR4
2 / 3
OSFP 4x200G FR4
3 / 3

800G OSFP (200G per lane)

Eoptolink 200G/lane 800G OSFP transceivers are compliant to the latest releases of the OSP MSAs. The firmware supports CMIS 5.0 and newer releases. We offer DR4, DR4-2, FR4, VR4 and 2FR2 transceivers for different reach and applications.

    • OSFP MSA Compliant
    • 4x226.6 Gb/s (PAM4) optical interface
    • 8x106.25 Gb/s (PAM4) electrical interface
    • 0°C to 70°C
    • CMIS 5.0 or higher support
    Part No. Description Data Rate Wavelength Distance Connector Temp.
    EOLO-138HG-E-5H-XDX OSFP 800G DR4 4x200G, 800GbE 1311nm 500m MPO-12 C
    EOLO-138HG-E-02-XDX OSFP 800G DR4-2 4x200G, 800GbE 1311nm 2km MPO-12 C
    EOLO-168HG-E-02-XXX
    EOLO-168HG-E-02-XCX    		 OSFP 800G 2FR2 4x200G, 2x400GbE 1291/1311nm 2km Dual Duplex LC
    Dual CS    		 C
    EOLO-168HG-E-02-XPX OSFP 800G FR4 4x200G, 800GbE CWDM 2km Duplex LC C
    EOLO-858HG-E-01-DXX OSFP 800G VR4 4x200G, 800GbE 850nm TBD MPO-12 C

    For the latest specification and samples, please, contact us This email address is being protected from spambots. You need JavaScript enabled to view it.
